Polar Mobility Research Heavy-Duty HVAC Systems
Since 1985 Polar Mobility Research has been active in the research, manufacture and distribution of mobile heavy-duty heating, ventilation and air conditioning (HVAC) solutions, providing systems to clients in the mining, municipal, construction, agriculture, railway, forestry, trucking and military industries worldwide.
Non-electric air conditioning system
Polar’s P-1000 FH air conditioning system is compact and easy to install. The fully hydraulic design of the P-1000 FH non-electric unit eliminates the need for all electrical power, making it virtually explosion-proof. It is designed to exceed all hazardous location requirements, and is manufactured with MSHA-rated components, making it suitable for any application. Features include:
- Stainless-steel case construction
- Extremely efficient high-volume hydraulic fan motors
- Heavy-duty vibration-resistant construction
- Polar HD hydraulic drive compressor package
- 20,000 – 50,000 BTU/hr output
- Two-year limited warranty
Heavy-duty A/C split system
The P-1320 / 320 heavy-duty A/C unit is a split system of condenser and evaporator. It is extremely robust and requires little maintenance, providing exceptionally high cooling capacity and uninterrupted, long-lasting service, even in the harshest environmental conditions. The P-1320 / 320 is ideal for underground mining machinery, refuge stations and mining equipment, such as shovels, dozers, haul trucks, loaders, cranes, excavators and drills.
Heavy-duty condensers
The P-1325 heavy-duty condenser is designed for use in any 24VDC machine application, including haul trucks, graders, dozers and loaders. It replaces the conventional engine driven compressor and radiator mounted condenser, and can tie into the factory cab A/C system and controls. The P-1325 offers a wide variety of mounting configurations and is extremely flexible. Features include:
- 20,000 BTU condenser capacity
- >60A at 24VDC
- Dimensions: 27in (W) x 16 1/4in (D) x 11in (H)
The P-1900 heavy-duty condenser is suitable for use in any high dust or vibration application, including haul trucks, graders, dozers and loaders. It is designed to replace the conventional radiator mounted condenser, and can integrate with the factory cab A/C system and controls. Features include:
- 35,000 BTU condenser capacity
- >10A at 24VDC
- Dimensions: 28 3/4in (W) x 11 5/16in (D) x 14 1/2in (H)
Through-wall HVAC system
The P-5225 through-wall HVAC system is a heavy-duty A/C unit designed for use in large cabs and dusty locations. It has been developed to provide outstanding air quality, helping to make any environmental enclosure a safe, dust-free working environment. The dimensions of the unit are 31in (W) x 25in (D) x 48 1/8in (H), and it weighs around 220lbs. Several power options are available:
- 24VDC, 200 – 575VAC three-phase
- 50Hz or 60Hz, 200 – 270VAC
- One-phase 50Hz or 60Hz max. amp draw
- Cooling 24A, heating 32A
Rooftop air conditioners
The P-5070 and P-9977 models are high-capacity A/C units designed for use in mining, oil field, military and heavy equipment applications. They can easily handle the rugged environments and extreme temperature conditions found in mine sites around the world. These units create a comfortable, dust-free and temperature-controlled cab environment, significantly reducing operator fatigue. They are easy to install and require very little maintenance.
The P-5070 all electric rooftop air conditioner can operate in ambient temperatures exceeding 55°C / 130°F. It weighs approximately 205lbs and its dimensions are 28in (W) x 34 1/8in (D) x 17 9/16in (H). The P-9977 rooftop air conditioner operates in ambient temperatures of 55ºC / 130ºF. Its dimensions are 29in (W) x 35 1/2in (D) x 12 1/2in (H).
Hydraulic driven heater / air conditioner
The P-9990 heavy-duty hydraulic driven heater / air conditioner is a self-contained unit that is suitable for use anywhere that dependable HVAC is required. It is designed to attach to the rear or side wall of the cabin with air flow ducted inside. Two models are available:
- P-9990-H-24P: for use in -45°C to 50°C (-49°F to 122°F); 20,000 BTU cooling capacity; 30,000 BTU heat – requires engine coolant lines
- P-9990-RC-24P: for use in -30°C to 50°C (-22°F to 120°F); 20,000 BTU cooling capacity; 18,000 BTU heat – no coolant lines required
Make an enquiry
7860 62nd Street SE
Calgary
T2C 5K2
Alberta
Canada
Polar Mobility Research Images
Products and Services
P-1000 FH and P-1320 / 320
The Polar P-1000 FH fully hydraulic mining air-conditioner is designed to suit the rigorous requirements of the mining industry. It is suitable for heavy equipment, such as shovels, dozers, haul trucks, loaders, excavators, drills and underground equipment.
P-1900, P-1325 and P-1326
The robust P-1900 condenser has been developed for use in any high-dust or vibration application, including haul trucks, graders, dozers, and loaders used in mining applications.
P-5070 and P-9977
The P-5070 rooftop-mount, self-contained climate control system is designed for rough environments and extreme high-temperature conditions found at mine sites worldwide.
P-5225 and P-5200
The P-5225 high-capacity air-conditioning wall mount unit has a digital automatic control system with high-output cooling capacities. The system is engineered for ambient temperatures of 50°c / 122°F, providing a comfortable working environment for operators.
P-9990-FE and P-9990-H
The heavy-duty P-9990-FE modular electric drive air-conditioning unit is capable of withstanding harsh environment and extreme temperatures often found in mining projects.
